XK-CM111
Add to Info-List

2.4/5 GHz Antenna and Extension Cable

2.4/5 GHz Antenna and Extension Cable. Consists of one Dual-Band Antenna with 50-Ohm RP-SMA connector with Magnetic Mount. Gain: 3 dBi @ 2400 - 2483 MHz; 5 dBi @ 5150 - 5900 MHz; VSWR < 2.0:1 and one Adapter Cable (50-Ohm MCX connector to 50-Ohm RP-SMA connector)

Physical Attributes:
  • Size:
    - Adapter Cable length is approximately 8 inches (203 mm)
    - Antenna
    • Height: 10.5 inches (267 mm)
    • Base: 1.6 inch diameter (41 mm)
    • Antenna Cable: 60 inches (1.5 meters)
    • Weight: < 0.25 lbs. (< 0.11 Kg)
  • Operating Temperature: -30...+60°C: 90% humidity non-condensing
  • Storage Temperature: -40°...+85°C
Ordering Options
Manuf. Part No    Part Description
XK-CM111  2.4/5 GHz Antenna and Adapter Cable (Quantity of three recommended for use with WLAN25203ER & WLAN35203ER)
