WLAN35203ER WLAN25203ER
Add to Info-List

Dual-Slot Mini PCIe Card Carriers with Atheros WLAN Module

The WLAN25203 and WLAN35203 are dual-slot mini PCIe card carrier modules with an Atheros AR9590 WLAN module installed. The dual-band design of the Atheros module enables universal connectivity to any 802.11 network, including legacy 802.11b/g and 802.11a/g.

Features
  • PC/104 form factor
  • Bus Structure Options:
    • PCIe/104 (WLAN35203ER)
       ▫ PCIe universal expansion bus (Type 1 or Type 2)
    • PCI/104-Express (WLAN25203ER)
       ▫ PCIe universal expansion bus (Type 1 or Type 2)
       ▫ PCI pass-through expansion bus
  • Available in stackable, rugged enclosures
  • PCIe x1 interface (Gen 2, 5 GT/s)
  • PCIe link repopulation allowing increased PCI Express stack capacity
  • Atheros AR9590 WLAN Mini PCI Express Card
    • Compliant to IEEE Standards: 802.11a/b/g/n
    • Support for 3x3 MIMO with spatial multiplexing
    • Supports up to 450Mbps physical data rates
    • Dual-band 2.4GHz and 5GHz with 20/40MHz channel width
    • Supports 802.11x authentication, 64/128/152Bit WEP, IEEE802.11i encryption
    • Multi-Country Roaming Supported (IEEE802.11d Global Harmonization Standard)
    • Driver support for XP/7 and Linux operating systems
    • Compliant with PCI-Express Mini Card 1.1 Standard
    • Operating Temp range: -20 to +70°
  • WAKE# signal supported on both PCIe slots
  • Note: Atheros AR9590 does not support W_DISABLE#
  • Selected mini PCIe cards may affect standard operating temperature
  • Requires only +5 VDC for operation
  • Also available without Mini PCIe card: IM25100HR & IM35100HR
Available in stackable, rugged IDAN enclosures: IDAN-WLAN35203ER and IDAN-WLAN25203ER
Ordering Options
Manuf. Part No  Part Description
WLAN35203ER  PCIe/104 Mini-PCIe Card Carrier Module with Atheros WLAN Module
WLAN25203ER  PCI/104-Express Mini-PCIe Card Carrier Module with Atheros WLAN Module

Accessories
Manuf. Part No  Part Description
XK-CM111  antenna (qty. 3 recommended)
Zubehör // Accessories to TOP
XK-CM111

RTD 		XK-CM111 2.4/5 GHz Antenna and Extension Cable 2.4/5 GHz Antenna and Extension Cable
2.4/5 GHz Antenna and Extension Cable more
