The VID34860 is a PCIe/104 video controller that uses the AMD Radeon E8860 GPU. This powerful video controller offers 5 video outputs, all of which may be used simultaneously. By supporting DisplayPort++, the video outputs can interface with almost any standard monitor (analog or digital). The VID34860 provides an excellent power to performance ratio with the use of AMD PowerPlay technology. By utilizing the PCIe x4 link the VID34860 provides external GPU support to CPUs with a PCIe x4 link.
Features
- PC/104 form factor
- PCIe/104 stackable bus structure
- Available in stackable, rugged enclosures
- AMD Radeon E8860 GPU
• 640 shader processors
• 128-bit memory interface with 2GB GDDR5
• Microsoft® DirectX® 11.1 support
• Fourth generation video decoder
• Support for H.264, VC-1, MPEG-2/4 decode
• Dual HD decode, Blu-ray & Stereo 3D
• Up to 5 simultaneous displays with AMD Eyefinity technology
• AMD Accelerated Parallel Processing (APP) technology
- Versatile Video Output
• Analog and Digital
• DisplayPort++ enables support for any common video output standard
• Analog VGA
• DisplayPort
• DVI
• HDMI
• Supports 4K resolution
- Utilizes the PCIe x4 Link (Gen 3, 8 GT/s)
- Optimized profile heat sink with mini-fan included
Compatible with RTD these CPUs:
- Intel Core i7
• CMA34CRS1500HR (PCIe/104, 1.5 GHz Single-Core)
• CMA34CRD1700HR (PCIe/104, 1.7 GHz Dual-Core)
• CMA34CRQ2100HR (PCIe/104, 2.1 GHz Quad-Core)
Click here for the CMA34CR product page
Also available in a stackable, rugged IDAN enclosure
Ordering Options
| Manuf. Part No | | Part Description |
| VID34860ER | | PCIe/104 Video Controller with AMD Radeon E8860 |
Accessories
| Manuf. Part No | | Part Description |
| XK-CM37 | | Analog VGA Cable |
|
