The ToughNet TN-G4500 Series M12 managed Ethernet switches are designed for railway applications, including rolling stock and wayside
installations. These switches are equipped with M12 and similar circular connectors to ensure tight, robust connections, and guarantee reliable
operation in industrial environments where vibrations and shock are commonplace.
The TN-G4500 Series Ethernet switches provide 4 10G Ethernet M12 ports with PoE functionality, 16 Gigabit Ethernet M12 ports, and 8 ports with PoE functionality. These PoE switches are classified as power source equipment (PSE), capable of providing up to 30 watts of power per port to power IEEE 802.3at/af-compliant powered devices (PDs), such as IP cameras and wireless access points.
The TN-G4500 Series has M12 connectors that are tailor-made for push-pull cables to facilitate quick installation and also allow M12 rotary cables
to be utilized. The 24 to 110 VDC wide power input range and isolated dual-power inputs not only allow you to use the same type of power source
at different sites around the globe, but also increase the reliability of your communications system. Furthermore, the -40 to 70°C wide operating
temperature allows deployment in harsh environments. The TN-G4500 Series complies with the essential sections of the EN 50155 standard,
covering operating temperature, power input voltage, surge, ESD, vibration, power isolation, and includes models with conformal coating to ensure
suitability for a variety of industrial applications.
Features
- 4 10G ports and 12 Gigabit ports with push-pull M12 connectors
- Isolated power with wide 24...110 VDC power supply range
- Complies with all EN 50155 mandatory test items*
- -40...+70°C operating temperature range
- Turbo Ring and Turbo Chain (recovery time < 50 ms @ 250 switches), and STP/RSTP for network redundancy
- 12 IEEE 802.3at/af compliant PoE and Ethernet combo ports
- Provides up to 30 watts per PoE port
- Standards and Certifications
- EMC: EN 55032/35
- Rail Traffic: EN 50121-4, EN 50155, IEC 60571
- Railway Fire Protection: EN 45545-2
- Shock: IEC 60068-2-27, IEC 61373, EN 50155
- Freefall: IEC 60068-2-31
- Radio Frequency: FCC
- Vibration: IEC 60068-2-64, IEC 61373, EN 50155
- Safety: IEC 62368-1, UL 62368-1
- 5 Years Warranty
*This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard.
Ordering Options
| Manufacturers_Model_Name | | 10/100/1000 BaseT(X) Ports, M12 X-coded 8-pin Female Connector | | 10G BaseT(X) Ports, M12 X-coded 8-pin Female Connector With Bypass Relay | | 100/1000 BaseT(X) PoE Ports, M12 X-coded 8-pin Female Connector | | 10G BaseT(X) PoE Ports, M12 X-coded 8-pin Female Connector | | Conformal Coating | |
| TN-G4516-8GPoE-4XGPoEWV-T | | 4 | | - | | 8 | | 4 | | No |
|
| TN-G4516-8GPoE-4XGPoEWV-CT-T | | 4 | | - | | 8 | | 4 | | Yes |
|
| TN-G4516-8GPoE-2XGPoE2XGTXBP-WV-T | | 4 | | 2 | | 8 | | 2 | | No |
|
| TN-G4516-8GPoE-2XGPoE2XGTXBP-WV-CT-T | | 4 | | 2 | | 8 | | 2 | | Yes |
|
Accessories
| Manuf. Part No | | Part Description | |
| A-CAP-M12M-M | | Metal cap for M12 male connector |
|
| A-CAP-M12F-M-PP | | Metal cap for M12 female push-pull connector |
|
| M12X-8PMM-IP67-HTG | | X-coded screw-in Gigabit Ethernet connector, 8-pin male M12 connector, IP67 |
|
| CBL-M12XMM8P-Y-300-IP67 | | M12-to-M12 Cat-5 UTP Ethernet cable, 8-pin male X-coded crimp type M12 connector, IP67, 3 m |
|
| CBL-M12XMM8PRJ45-Y-200-IP67 | | M12-to-RJ45 Cat-5 UTP Ethernet cable, 8-pin male X-coded crimp type M12 connector, IP67, 2 m |
|
| CBL-M12XMM8P-Y-100-IP67 | | M12-to-M12 Cat-5 UTP Ethernet cable, 8-pin male X-coded crimp type M12 connector, IP67, 1 m |
|
| CBL-M12KFF5POPEN-O-150-IP67 | | CBL-M12KFF5POPEN-O-150-IP67 |
|
| CBL-M12BMM5PF9-BK-150-IP68 | | CBL-M12BMM5PF9-BK-150-IP68 |
|
| ABC-02-P-USB-M12-CT-T | | USB-based configuration backup and restoration tool with M12 connector for Moxa’s ToughNet series of managed Ethernet switches and wireless APs/bridges/clients, -40...+75°C operating temperature, conformal coating |
|
|
