Foremay’s TC166 Family SSD drives are designed for with high reliability and
performance in rugged embedded computers and terminal computing machines for defense
and industrial applications such as aviation, government systems, oil field, mining, industrial robots, HPC and HPEC.
TC166 series application examples are
- Rugged PCs / Laptops
- Embedded PCs
- HPC and HPEP
Ordering Options
| Form Factor | | R/W Speed, Max. (MB/s) | | Capacity (GB) | | Optional Features |
| 2.5” SATA III | | 550/510 | | 30 ~ 16,000 | | HE, S1, S2, S3, WP |
| 3.5” SATA | | 550/510 | | 1000 ~ 32,000 | | HE, S1, S2, S3, WP |
| 1.8” microSATA | | 550/510 | | 30 ~ 2,000 | | HE, S1, S2, S3 |
| 1.8” SATA | | 550/510 | | 30 ~ 256 | | HE, S1, CC |
| 2.5“ IDE | | 100/80 | | 20 ~ 1,000 | | HE, S1, CC |
| CompactFlash | | 100/80 | | 30 ~ 128 | | HE, S1, CC |
| CFast | | 500/350 | | 30 ~ 256 | | HE, S1, CC |
| Optional Features |
| RC: Rugged connectors with 100K mating cycles |
| S1 & S2: software / hardware secure erase |
| S3: One-key self-destroy secure erase |
| HE: Hardware based encryptions |
| CC: Conformal coating |
| WP: Write protect (read only) |
|
