Rugged Wall-Mount Box: System Platform for Railway, Automotive, Industrial Applications
|
The SRS-12xx-BLUBRICK® is an embedded rugged system platform for a wide range of applications. The modular concept is based on CompactPCI® Serial, a well-established industrial standard for IEEE 100x1600mm2 size CPU- and I/O-boards. The SRS-12xx-BLUBRICK® comprises a 3-slot backplane and a DC power supply suitable for either automotive and industrial or railway usage.
The SRS-12xx-BLUBRICK® is available either as basic enclosure, equipped w. backplane and PSU, or turn-key ready configured with a CompactPCI® Serial CPU card and up to two I/O or SSD mass storage boards. The rugged box of extruded aluminium is provided with a mounting plate and available either for conductive cooling, or equipped with one or two fans for forced airflow.
Features
- Rugged enclosure for up to three CompactPCI® Serial bords (3 x 4HP)
- Dimensions profile 260 x 73 x 150.5 mm3
- Dimensions mounting flange 260 x 190.5 mm2
- 4 x Mounting slots 7mm x 5.5mm, distance 229mm x 170.5mm
- Any mounting position allowed
- DC power supply for railway, automotive or industrial application with wide input range
Applications
- Industrial computing (IoT), edge/fog
- Router, gateway, networking, data acquisition and acceleration, kiosk systems
- Automotive e.g. experimental autonomous cars, infotainment
- Railway applications (EN50155), e.g. alarm server
| SRS-xxxx-BLUBRICK | | Description |
| 1201 | | Rugged wall mount box, SRS-BLUBRICK series, housing with two fans, 2-Slot CompactPCI® Serial backplane, Power supply Vin 10-36VDC, P=60W, M12-A 4-position male connector |
| 1202 | | Rugged wall mount box, SRS-BLUBRICK series, housing with two fans, 2-Slot CompactPCI® Serial backplane coated, Coated power supply Vin 14-154VDC, P=40W, hold-up time 10ms, M12-A 4-position male connector |
| 1203 | | Rugged wall mount box, SRS-BLUBRICK series, housing with two fans, 2-Slot CompactPCI® Serial backplane, Power supply Vin 100-240VAC, P=50W, IEC connector |
| 1211 | | Rugged wall mount box, SRS-BLUBRICK series, closed housing w/o fans, 3-Slot CompactPCI® Serial backplane, Power supply Vin 10-36VDC, P=60W, M12-A 4-position male connector |
| 1212 | | Rugged wall mount box, SRS-BLUBRICK series, closed housing w/o fans, 3-Slot CompactPCI® Serial backplane coated, Coated power supply Vin 14-154VDC, P=40W, hold-up time 10ms, M12-A 4-position male connector |
| 1213 | | Rugged wall mount box, SRS-BLUBRICK series, closed housing w/o fans, 3-Slot CompactPCI® Serial backplane, Power supply Vin 100-240VAC, P=50W, IEC connector |
|
|
