The SPY-RIG is a peripheral slot card for CompactPCI® Serial systems. The board serves as a carrier for up to eight WWAN modules, e.g. 3G or 4G (LTE) modems, and also forthcoming technologies beyond 4G. Four M.2 sockets are provided to accommodate M.2 3042 style modules, related to front panel Mini SIM card slots. Another four WWAN modules are directly soldered to the PCB, combined with on-board Micro SIM card sockets.
The module antenna I/Os are strapped to an on-board 8:1 R/F combiner circuit, which has its sum port wired to the SMA type front panel antenna connector, for minimum external antenna cabling effort. The M.2 sockets support USB2 and USB3 based WWAN 3G/4G (LTE) and future 3042 size modules. The soldered 3G modems are USB2 controlled. The SPY-RIG is well suited especially for high throughput applications which require WWAN bandwidth aggregation.
Features
- PICMG® CompactPCI® Serial standard (CPCI-S.0) peripheral slot card
- Single size Eurocard 3U 4HP 100x160mm2
- CompactPCI® Serial backplane connector P1
- Suitable for PCIe® x1 or x2 Gen2 enabled peripheral slots
- On-board PCIe® packet switch PEX8605
Soldered WWAN Modules
- 4 x Telit HE910-GL quad band 3G embedded modules (global use version)
- DHSPA+ upload 5.76Mbps, download 7.2Mbps
- UMTS/HSPA MHz 800/850, 900, AWS1700, 1900, 2100
- On-board Micro SIM card holder associated to each module (default assignment)
- Analog crosspoint switches provided for SIM card sockets, optional selection between front slots and on-board sockets via I2C programming
Applications
- WWAN e.g. 3G/4G/LTE with data transfer rate aggregation
- Railway, transportation
- Industrial IoT networking
Please contact systerra computer GmbH for ordering options
|
