SPV-MYSTIC
Add to Info-List

CompactPCI® Serial Peripheral Card • WWAN Module Carrier

The SPV-MYSTIC is a six-fold WWAN module carrier card for CompactPCI® Serial systems. The front panel is provided with five Mini FAKRA quad style RF connectors and a single SMA jack for attachment of up to 21 antenna cables.

The board is equipped with four M.2 sockets suitable for WWAN 5G modules, and two soldered 4G modules in addition. Most F/P connector positions can be freely assigned to the M.2 WWAN modules by MHF4 patch cables. In addition, two 4:1 R/F combiner/splitter circuits are provided onboard, for optional reduction of external needed antennas. The SPV-MYSTIC is equipped with a PCIe® Gen3 packet switch. The M.2 sockets can be controlled via either PCIe® or USB3.

Features
  • PICMG® CompactPCI® Serial standard (CPCI-S.0) peripheral slot card
  • Single size Eurocard 3U 4HP 100x160mm2
  • Front panel width 4HP
  • Provides R/F front panel I/O
  • CompactPCI® Serial peripheral card slot (PCIe® enabled)
WWAN Modules
  • 4 x M.2 sockets, B-key, h=4.2mm, for WWAN 1-4
  • WWAN size either 3042 or 3052 (mounting hole positions)
  • up to 5G WWAN modules available as of current
  • USB2/3 connected (up to 5Gbps, Renesas uPD720201 on-board)
  • PCIe® connected (up to Gen3)
  • Dual nano-SIM card support (SIM card sockets on bottom of PCB)
  • Full card power on/off control optional via I2C
Please contact Systerra Computer GmbH for ordering options
