PMC-5565PIORC

2 GBaud Fiber-Optic Reflective Memory PMC Module

As a longstanding leader in Reflective Memory (RFM) technology, J-Squared understands the demands of real-time networks. We know that certain types of applications require the determinism, implementation simplicity, and lack of software overhead that ubiquitous technologies such as Ethernet can’t deliver.

Our PMC-5565PIORC Reflective Memory node card in PMC form factor is engineered specifically to provide highly deterministic, tightly timed performance for a variety of advanced networking applications that need to deterministically move large amounts of data fast and share that data in real time among similar or disparate network nodes.

J-Squared’s RFM products are designed to fit into your existing hardware and operating system environment, integrating diverse hardware platforms running different operating systems into a single, shared memory network.

The PMC-5565PIORC Reflective Memory node card is well-suited for industrial control applications in which implementation simplicity, a lack of software overhead, and bus structure and operating system independence are key factors, such as:
  • Aircraft simulators
  • Automated testing systems
  • Ship and submarine simulators
  • Aluminum rolling mill
  • Power plant simulators
  • Engine test stands
  • Industrial process control
  • High-speed data acquisition
  • PLCs
Features
  • Dynamic packet size, 4 to 64 bytes of data
  • Connection with multimode fiber up to 300 m, single mode fiber up to 10 km
  • Up to 256 nodes
  • Data written to memory in one node is also written to memory in all nodes on the network
  • High speed, easy to use fiber-optic network (2.12 Gbaud serially)
  • Transfer rate 43 Mbyte/s (4 byte packets) to 170 Mbyte/s (64 byte packets)
  • 128 Mbyte or 256 Mbyte SDRAM Reflective Memory
  • One independent DMA channel
  • Any node on the network can generate an interrupt in any other node on the network or in all network nodes with a single command
  • Error detection
  • Redundant transfer mode for extra error suppression
  • No processor overhead
  • No processor involvement in the operation of the network
  • PCI 64-bit 66 MHz transfers, 3.3 or 5 V, single width mezzanine interface
Ordering Options
Manuf. Part No    Part Description
PMC-5565PIORC-110000  PMC, 2 Gb/s RM, PIO-Mode, 128 MB Memory, 4 K FIFOs, multi-mode LC fiber-optic Interface
PMC-5565PIORC-111000  PMC, 2 Gb/s RM, PIO-Mode, 128 MB Memory, 4 K FIFOs, single-mode LWL Interface
PMC-5565PIORC-210000  PMC, 2 Gb/s RM, PIO-Mode, 256 MB Memory, 4 K FIFOs, multi-mode LWL Interface
PMC-5565PIORC-211000  PMC, 2 Gb/s RM, PIO-Mode, 256 MB Memory, 4 K FIFOs, single-mode LWL Interface
