As a longstanding leader in
Reflective Memory (RFM)
technology, J-Squared
understands the demands of
real-time networks. We know
that certain types of applications
require the determinism,
implementation simplicity, and
lack of software overhead that
ubiquitous technologies such as
Ethernet can’t deliver.
Our PCIE-5565PIORC Reflective
Memory node card in low profile
PCI Express form factor is
engineered specifically to provide
highly deterministic, tightly timed
performance for a variety of
advanced networking applications
that need to deterministically
move large amounts of data
fast and share that data in real
time among similar or disparate
network nodes.
J-Squared’s RFM products are
designed to fit into your existing
hardware and operating system
environment, integrating diverse
hardware platforms running
different operating systems
into a single, shared memory
network.
The PCIE-5565PIORC is well suited for industrial control applications in which
implementation simplicity, a lack of Software overhead, and bus structure and
operating system independence are key factors, such as:
- Aircraft simulators
- Automated testing systems
- Ship and submarine simulators
- Aluminum rolling mill
- Power plant simulators
- Engine test stands
- Industrial process control
- High-speed data acquisition
- PLCs
PCI Express, PMC, PCI and VME node Interface cards are available, and we support a wide variety of operating systems.
Features
- Low latency, deterministic transfer rates: Achieve predictable, high-performance application deployment
- Operating system and bus structure independence: Integrate diverse systems into a single, shared memory network
- Transparent data transfers between nodes: Eliminates processor overhead and Delivers higher levels of performance
- Error management and detection: Protects against lost dataspace.
- RFM network supports up to 256 nodes: Enables the scalability to build the network to fit the application and add more nodes when needed
- 2.12Gbaud serial connection speed: Transfer data faster between nodes
- 128 or 256 Mbytes of onboard SDRAM: Share large amounts of data
- Transfer rate 43 Mbyte/s (4 byte packets) to 170 Mbyte/s (64 byte packets)
- Dynamic packet size, 4 to 64 bytes of data
- Connection with multimode fiber up to 300m, single mode fiber up to 10km
- Data written to memory in one node is also written to memory in all nodes on the network
- High speed, easy to use fiber-optic network (2.12 Gbaud serially)
- No processor overhead
- No processor involvement in the operation of the network
- PCI Express 2.5GHz signaling
Ordering Options
| Manuf. Part No | | Part Description |
| PCIE-5565PIORC-100000 | | High-profile PCI Express, 2 GIGA Baud RM w/FO options, 128 MByte memory, multimode transmission. |
| PCIE-5565PIORC-200000 | | High-profile PCI Express, 2 GIGA Baud RM w/FO options, 256 MByte memory, multimode transmission. |
| PCIE-5565PIORC-101000 | | High-profile PCI Express, 2 GIGA Baud RM w/FO options, 128 MByte memory, singlemode transmission. |
| PCIE-5565PIORC-201000 | | High-profile PCI Express, 2 GIGA Baud RM w/FO options, 256 MByte memory, singlemode transmission. |
| PCIE-5565PIORC-100100 | | Low-profile PCI Express, 2 GIGA Baud RM w/FO options, 128 MByte memory, multimode transmission. |
| PCIE-5565PIORC-200100 | | Low-profile PCI Express, 2 GIGA Baud RM w/FO options, 256 MByte memory, multimode transmission. |
| PCIE-5565PIORC-101100 | | Low-profile PCI Express, 2 GIGA Baud RM w/FO options, 128 MByte memory, singlemode transmission. |
| PCIE-5565PIORC-201100 | | Low-profile PCI Express, 2 GIGA Baud RM w/FO options, 256 MByte memory, singlemode transmission. |
|
