As a longstanding leader in
Reflective Memory (RFM)
technology, J-Squared
understands the demands of
real-time networks. We know
that certain types of applications
require the determinism,
implementation simplicity, and
lack of software overhead that
ubiquitous technologies such as
Ethernet can’t deliver.
Our PCI-5565PIORC Reflective
Memory node card in PCI form
factor is engineered specifically
to provide highly deterministic,
tightly timed performance for a
variety of advanced networking
applications that need to
deterministically move large
amounts of data fast and share
that data in real time among
similar or disparate network
nodes.
J-Squared’s RFM products are
designed to fit into your existing
hardware and operating system
environment, integrating diverse
hardware platforms running
different operating systems
into a single, shared memory
network.
The PCI-5565PIORC is well-suited for industrial
control applications in which implementation
simplicity, a lack of software overhead, and bus
structure and operating system independence are
key factors, such as:
- Aircraft simulators
- Automated testing systems
- Ship and submarine simulators
- Aluminum rolling mill
- Power plant simulators
- Engine test stands
- Industrial process control
- High-speed data acquisition
- PLCs
Features
- High speed, easy to use fiber-optic network (2.12 Gbaud serially)
- Data written to memory in one node is also written to memory in all nodes on the network
- Up to 256 nodes
- Connection with multimode fiber up to 300 m, single mode fiber up to 10 km
- Dynamic packet size, 4 to 64 bytes of data
- Transfer rate 43 MB/s (4 byte packets) to 174 MB/s (64 byte packets)
- 64 MB or 128 MB SDRAM Reflective Memory
- Two independent DMA channels
- Any node on the network can generate an interrupt in any other node on the network or in all network nodes with a single command
- Error detection
- Redundant transfer mode for extra error suppression
- No processor overhead
- No processor involvement in the operation of the network
- PCI 64-bit 66 MHz transfers, 3.3 or 5V, single width mezzanine interface
- Please call for Windows Drivers (available Windows 7/XP/Vista/Server 2008/Server 2003, 32/64-bit for PCIE/PCI/PMC)
Ordering Options
| Manuf. Part No | | Part Description | | Memory | | Fiber Interface |
| PCI-5565PIORC-110000 | | PCI Refective Memory Board | | 128 MB | | multi-mode |
| PCI-5565PIORC-111000 | | PCI Refective Memory Board | | 128 MB | | single-mode |
| PCI-5565PIORC-210000 | | PCI Refective Memory Board | | 256 MB | | multi-mode |
| PCI-5565PIORC-211000 | | PCI Refective Memory Board | | 256 MB | | single-mode |
All versions are euquipped with 4k FIFO
|
