Foremay’s OC177 Family are caseless rugged SSD drives designed for compact yet robust systems for mission critical and industrial applications. It features high
integration with motherboards which is essential for rugged single board computers (SBC) and other rugged compact computing machines.
OC177 series application examples are
- Rugged Laptops & Tablets
- Wearable Weapons
- Single Board Computers
- Embedded / Industrial PCs
- Rugged Handheld Devices
- Rugged GPS Terminals
- UAV / Remote Drone
- Industrial Robotics
- Other SBC, Compact and Miniature Computers
Ordering Options OC177 Hi-Rel ™ Series, industrial grade and/or military grade solid state drives for mission critical applications, Operating temperature: -40~+85°C or wider
| Form Factor | | R/W Speed, Max. (MB/s) | | Capacity (GB) | | Optional Features |
| mSATA III (MO-300B), 30x50 mm | | 550/510 | | 30 ~ 120 GB | | S1, HE, CC |
| mSATA III (MO-300B), 30x25 mm | | 550/510 | | 30 ~ 60 GB | | S1, HE, CC |
| half slim SATA III (MO-297A) | | 500/500 | | 30 ~ 120 GB | | S1, HE, CC |
| SATA DOC® (BGA NAND Drive) | | 450/200 | | 16 ~ 64GB | | S1, HE |
| 1.8" micro SATA | | 260/260 | | 32 ~ 240 GB | | S1, HE, CC |
| 1.8" SATA | | 260/260 | | 32 ~ 128 GB | | S1, HE, CC |
| 1.8" ZIF / IDE | | 100/95 | | 32 ~ 128 GB | | S1, HE, CC |
| M.2 NGFF | | 450/350 | | 32 ~ 256 GB | | S1, HE, CC |
Ordering Options OC177 ™ G-Series, Operating temperature: 0~+70°C or wider
| Form Factor | | R/W Speed, Max. (MB/s) | | Capacity (GB) | | Optional Features |
| mSATA III (MO-300B), 30x50 mm | | 550/510 | | 30 ~ 240 GB | | S1, HE, CC |
| mSATA III (MO-300B), 30x25 mm | | 550/510 | | 30 ~ 120 GB | | S1, HE, CC |
| half slim SATA III (MO-297A) | | 500/500 | | 30 ~ 240 GB | | S1, HE, CC |
| SATA DOC® (BGA NAND Drive) | | 450/200 | | 16 ~ 64GB | | S1, HE |
| 1.8" micro SATA | | 260/260 | | 32 ~ 512 GB | | S1, HE, CC |
| 1.8" SATA | | 260/260 | | 32 ~ 256 GB | | S1, HE, CC |
| 1.8" ZIF / IDE | | 100/95 | | 32 ~ 256 GB | | S1, HE, CC |
| M.2 NGFF | | 450/350 | | 32 ~ 1000 GB | | S1, HE, CC |
| Optional Features |
| S1: Type-I software secure erase |
| HE: Encryption |
| CC: Conformal coating |
|
