IDAN-SATA34106HRS

Stackable Packaging Systems for SATA34106HR 2.5 inch Hard Drive Carriers

Stackable Packaging Systems for SATA34106HR 2.5 inch Hard Drive Carriers.

Features:

PCIe/104 stackable bus structure
- PCIe Type 2 expansion bus
- SATA Interface with lane shifting
Modular rugged milled aluminum frames
Maintains the PC/104 bus self-stacking concept
Allows quick interchangeability of modules
Frame includes SATA34106 hard drive carrier
Aluminum Alloy - 6061, Temper-T6
Finish - MIL-PRF-85285 polyurethane topcoat, per FED-STD-595, color 36495 (light gray). Panel engravings per FED-STD-595, color 37038 (black).
- Additional paint options available upon request
Requires additional SATA controller (note that RTD CPUs with Type 2 PCI Experss connectors satisfy this requirement)
Supports 2.5 inch flash drives

Ordering Options

Manuf. Part No		Part Description
IDAN-SATA34106HRS		PCIe/104 2.5" SATA Drive Carrier
IDAN-SATA34106HRS/FSxx		2.5" Hard Drive Carrier with Apacer Flash Drive Installed (hard drive options available)

Click here for Removable Drive Options
