IDAN-IOM35106ER

Stackable Packaging System for RTD's IOM35106 SATA Controller

Stackable Packaging System for RTD's IOM35106 SATA Controller. The IOM35106 is designed to provide a PCI Express (PCIe) to SATA Controller. It uses a PCIe x1 link to provide two SATA connections links. The onboard drive utilizes the first SATA link provide by the controller, while the second link utilizes the right angle connector and will need external out-of-stack cabling.

Features:
  • PCIe/104 stackable bus structure
    - PCIe universal expansion bus (Type 1 or Type 2)
  • PCIe x1 interface
  • Modular rugged milled aluminum frames
  • Maintains the PC/104 bus self-stacking concept
  • Allows quick interchangeability of modules
  • Frame includes IOM35106ER SATA controller
  • Aluminum Alloy - 6061, Temper-T6
  • Finish - MIL-PRF-85285 polyurethane topcoat, per FED-STD-595, color 36495 (light gray). Panel engravings per FED-STD-595, color 37038 (black).
    • Additional paint options available upon request
Physical Attributes
  • Dimensions
    • Length: 5.983 inches (152 mm)
    • Width: 5.117 inches (130 mm)
    • Height: 0.669 inches (17 mm)
  • Weight: Approximately 0.46 lbs. (0.21 Kg)
  • Standard Operating Temperature
    • 90% humidity non-condensing: 0...+70°C
  • Storage Temperature: -40...+85°C
  • Input Power Requirements: +5 VDC
Ordering Options
Manuf. Part No    Part Description
IDAN‑IOM35106ERS  PCIe/104 SATA Controller
