RTD's IDAN-Configuration for the Cisco 5915 Embedded Services Router. This system enables the deployment of Cisco Mobile Ready Net capabilities in mobile, air, ground and unmanned applications.
Features
- PCI/104-Express stackable bus structure
• PCIe universal expansion bus (Type 1 or Type 2)
• PCI pass-through expansion bus
- Modular rugged milled aluminum frames
- Maintains the PC/104 bus self-stacking concept
- Allows quick interchangeability of modules
- Two configurations available
• Upward stacking
• Downward stacking
- Frame includes:
• Cisco 5915 Embedded Services Router
• Integral passive heat sink
• RJ-45 jacks and status LEDs
• Factory default initiation button
- Cisco 5915 Router Features
• Cisco IOS 15.x Operating System
• Enterprise Base software standard
- Industry-standard Cisco IOS command set and configuration
- Support for WAN connection redundancy on Routed ports: Primary and Backup Interface, IP SLA
- VLAN Support: Up to 32 VLANs, 802.1q Trunking
- Standard routing protocols such as RIP, OSPF, BGP
- PPP and PPPoE
- Network Address Translation (NAT)
- DHCP client, server, and relay
- Traffic Management (QoS, 802.1p)
- Management via Serial Console, Telnet, HTTP, SNMP
• Optional Advanced Enterprise software adds the following features:
- Cisco IOS Service Advertisement Framework (SAF)
- MLD Proxy
- IPv6 Support
- Firewall and Intrusion Prevention
- VPN Support
- Radio-aware routing (DLEP, R2CP, RFC 5578)
- OSPFv3 Support for Ad Hoc Mobile Networks
- Mobile IP
- Security and Cryptography Features (IPsec, AES, IKE, Suite-B, SSL/TLS, PKI)
- Cisco Unified Communications Manager Express support (up to 48 phones)
- Secure Shell (SSH) Client and Server
• Cisco Mobile Ready Net capabilities
• Highly secure data, voice, and video communication
• Onboard hardware encryption
• 512 MB DRAM
• 256 MB Flash Memory
- Aluminum Alloy - 6061, Temper-T6
- Finish - MIL-PRF-85285 polyurethane topcoat, per FED-STD-595, color 36495 (light gray). Panel engravings per FED-STD-595, color 37038 (black).
• Additional paint options available upon request
- Compatible with RTD's scalable Gigabit Ethernet switches
Ordering Options
| Manuf. Part No | | Part Description |
| IDAN‑ID5915D‑4E | | Cisco 5915 Router in modular IDAN configuration (single slice) Top of Stack or Stand-alone, Cisco IOS Enterprise Base, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
| IDAN‑ID5915U‑4E | | Cisco 5915 Router in modular IDAN configuration (single slice) Bottom of Stack or Stand-alone, Cisco IOS Enterprise Base, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
| IDAN‑ID5915D‑4A | | Cisco 5915 Router in modular IDAN configuration (single slice) Top of Stack or Stand-alone, Cisco IOS Advanced Enterprise, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
| IDAN‑ID5915U‑4A | | Cisco 5915 Router in modular IDAN configuration (single slice) Bottom of Stack or Stand-alone, Cisco IOS Advanced Enterprise, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
| IDAN‑eB5915‑4E | | Cisco 5915 Router in Pre-Configured IDAN (complete system), includes IDAN-ATX3510HR-190W Power Supply, Lid, Base and Bolts. Cisco IOS Enterprise Base, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
| IDAN‑eB5915‑4A | | Cisco 5915 Router in Pre-Configured IDAN (complete system), includes IDAN-ATX3510HR-190W Power Supply, Lid, Base and Bolts. Cisco IOS Advanced Enterprise, 1-year RTD standard warranty, 1-year Cisco tech support and IOS updates |
