IDAN-CMT36106HR

Stackable Packaging System for CMT36106HR PC/104 IDE Drive Carrier Peripheral Module

Stackable Packaging System for CMT36106HR. The CMT3106ER and CMT36106HR provide a 2.5" IDE drive interface through the EIDE bus.

Features

PC/104 form factor
Modular rugged milled aluminum frames
Maintains the PC/104 bus self-stacking concept
Allows quick interchangeability of modules
Frame includes a CMT36106HR hard drive carrier
Aluminum Alloy - 6061, Temper-T6
Finish - MIL-PRF-85285 polyurethane topcoat, per FED-STD-595, color 36495 (light gray). Panel engravings per FED-STD-595, color 37038 (black).
• Additional paint options available upon request
Decodes the IDE interface from the EIDE bus
Requires additional EIDE controller
• Available with AMD Geode™ LX Series Single Board Computers
Supports:
• IDE ATA series 2.5" rotating drives
• IDE ATA series 2.5" Flash drives

Physical Attributes

Dimensions
• Length: 5.983 inches (152 mm)
• Width: 5.117 inches (130 mm)
• Height: 0.669 inches (17 mm)
Weight: Approximately 0.64 lbs. (0.30 Kg)
Standard Operating Temperature: 90% humidity non-condensing: -40...+85°C
Storage Temperature: -55...+125°C
Power requirements: +5 VDC

Ordering Options

Manuf. Part No		Part Description
IDAN-CMT36106HRS		2.5-inch hard drive carrier in modular IDAN frame
