IDAN-CMA34KB
Add to Info-List

Stackable Packaging System for CMX34KB PCIe/104 Single Board Computers & Controllers

Stackable Packaging System for CMX34KB PCIe/104 Single Board Computers & Controllers. Includes SATA34106HR 2.5" Hard Drive Carrier

Features
  • PCIe/104 stackable bus structure
    • PCIe Type 2 expansion buses
  • Complete PC-compatible Single Board Computer (SBC)
  • Intel Xeon E3-1500 Series Processors
    • Xeon E3-1505L V6
    - 4 Cores, 8 Threads
    - 2.2 GHz Clock Speed
    - 3.0 GHz Max Turbo Frequency
    - 100°C Max. Core Temperature
    • Xeon E3-1505M V6
    - 4 Cores, 8 Threads
    - 3.0 GHz Clock Speed
    - 4.0 GHz Max Turbo Frequency
    - 100°C Max. Core Temperature
  • 16GB Dual-Channel DDR4 SDRAM (Surface-Mounted)
    • Robust Error Code Correction (ECC)
  • 32GB standard surface-mounted industrial-grade SATA flash drive
  • Five added SATA Ports
  • Four x4 PCIe Links
  • Eight x1 PCIe Links
  • Dual Gigabit Ethernet
  • Four Serial Ports (RS-232/422/485)
  • Five USB 3.0 Ports (one on-board, four on expansion buses)
    • Can also be used with USB 2.0 devices
  • Two USB 2.0 Ports
  • DisplayPort 1.2
    • Supports 4K resolution
    • Includes Audio
  • Advanced Digital I/O (aDIO)
  • Trusted Platform Module (TPM)
    • Fully compliant to the Trusted Computing Group (TCG) Trusted Platform Module (TPM) version 2.0 specification, Level 00, Revision 1.38
    • Provides for secure storage of cryptographic keys
  • Heat Sink Options
    • Thermal-optimized mini-fan heat sink included (standard)
    • Modified heat sinks and flat heat spreaders are available
    • The optional heat spreader shown on this page is designed for mounting to a cold plate
  • For all RTD products, modifications are available upon request
Ordering Options
Manufacturer Part Number   Processor Brand Name  Clock Speed (GHz)  DDR4 SDRAM  SSD
IDAN‑CMX34KBQ2200HR‑16384/S32GX   Intel Xeon E3‑1505L v6  2.2  16GB  32GB
IDAN‑CMX34KBQ3000HR‑16384/S32GX   Intel Xeon E3‑1505M v6  3.0  16GB  32GB

Accessories
Manuf. Part No    Part Description
XK-CM117 Cable Kit  Breaks a 9-pin dual RS-232 D-sub into two 9-pin D-subs
XK-CM118 Cable Kit  Breaks a 9-pin dual RS422/485 D-sub into two 9-pin D-subs
