IDAN-AC/DC PS-190

AC to DC Power Converter for use with IDAN-ATX3510HR-190W

AC to DC Power Converter for use with IDAN-ATX3510HR-190W

Features

AC to DC Power Converter
6-wire stranded
Input
- Standard three prong power connector
- 110-240 VAC 2.5-1.2A @ 50-60 Hz
Output
- 6-pin quick release connector
- 24 VDC 9.2A
Includes AC power cable
For use with IDAN-ATX3510HR-190W
Other configurations available:
- Board-level configuration for AC/DC PS-190
- Standard board-level AC/DC Power Supply
- Standard IDAN AC/DC Power Supply
Physical Attributes
Size (approximate):
- Length: 8.25 inches (209.55 mm)
- Width: 4.25 inches (107.95 mm)
- Height: 2.00 inches (50.80 mm)
- Cable length 36 inches
- AC power cable length 68 inches
Weight (approximate): 3.10 lbs. (1.41 Kg)
Operating Temperature: 0...+70°C, 5% to 90% humidity non-condensing (derate above +40...60% of full load at +70°C)
Storage Temperature: -25...+85°C

Ordering Options

Manuf. Part No.		Product Description
IDAN-AC/DC PS-190		External AC Power Supply for use with ATX3510HR-190W
