HiDANplus HDP1051
Add to Info-List

Rugged Embedded Mission Computer with DAQ

RTD's HDP1051 embedded computer system provides a robust Commercial-Off-the-Shelf (COTS) solution enabling rapid uptime for mission-critical applications. The system includes a high-reliability Intel Core i7 dual-core single board computer, a robust synchronous power supply, and a high-speed 12-bit data acquisition module.

The milled aluminum enclosure with advanced heat sinking and heat fins delivers passively-cooled performance from -40 to +85°C. Integrated tongue-and-groove architecture with EMI gaskets create a watertight solution with excellent environmental isolation. Keyed cylindrical connectors offer easy cable connections while maintaining the integrity of the environmental seal. A comprehensive development cable kit is available.

Features
  • Intel® Core i7 Dual-Core Processor with ECC Memory
  • 8GB DDR3 SDRAM
  • 32GB surface-mount industrial SATA flash drive (standard)
  • DM35425HR software-configurable 12-bit data acquisition module
  • ATX3510 synchronous power supply (194.8 W combined output)
  • COTS pre-configured with no additional engineering fees
  • Locking cylindrical connectors
  • Watertight, dust-tight design qualified to IP67 and IP69
  • -40...+85°C operating temperature
External Interface
  • MIL-DTL-38999 Series III cylindrical connectors with plug protection covers
  • COM: 2 full, 4 partial
  • PWR: power input, ON/OFF signaling, +5/+12 Vdc output, 8-36 Vdc input
  • LAN: dual Gigabit Ethernet
  • UTILITY: 4 USB, SVGA, CPU reset
  • L1: CPU status LED
  • L2: user-programmable LED
Please contact Systerra Computer GmbH for ordering options
