The HUB-5595 is a managed hub designed to
operate with the Abaco Systems 5565 family of
Reflective Memory real-time network products.
The Reflective Memory hub can automatically
bypass ports when it detects a loss of signal or the
loss of valid synchronization patterns, allowing the
other nodes in the network to remain operational.
Since the optical ports are implemented with small
form factor pluggable (SFP) transceivers, only the
required ports need to be populated. The hub’s
SFP transceivers can be a combination of either
multimode (short distance) or single-mode (long
distance) transceivers. This feature permits a
cost saving in small networks as well as system
optimization.
For larger networks, several hub assemblies can
be cascaded, permitting a managed hub array
with up to 256 nodes. Each port regenerates the
serial optical signal, eliminating the problems with
insertion losses and cable attenuation. Signal
regeneration also reduces jitter.
The RS232 port gives you the ability to monitor and
control your Reflective Memory network through
a simple PC serial port. The Ethernet port feature
allows you to monitor and control the hub from
great distances through a local area network (LAN)
or via a Web browser.
The HUB-5595 has a DIN rail mountable enclosure.
It operates on DC power, from 21VDC to 32VDC, to
permit use in many industrial environments.
Features
- For use with abaco 5565 Reflective Memory network of products
- Provides eight ports using small form factor pluggable (SFP) transceivers
- Hub assemblies can be cascaded with a maximum of 256 nodes
- Automatically bypasses defective or disconnected nodes in a fiber-optic network
- Automatic bypass can be optionally controlled by the loss of signal or by the loss of sync pattern
- Each port regenerates the serial optical signal, eliminating link losses and reducing jitter
- 10BaseT Ethernet TCP/IP port for remote access and control
- RS232 port for local access and control
- DIN rail mount enclosure uses 21...32 VDC power supply
- Dark on Dark option turns off the port’s transmitter if the receiver does not detect a signal (available for firmware versions 02.00 and later)
Ordering Options
| Manuf. Part No | | Part Description |
| HUB-5595-3 - A B C | | 2 GB/S REFLECTIVE MEMORY HUB WITH DIN RAIL MOUNT ENCLOSURE; A = Enclosure Options, B = Number of Single-Mode (10km) Pluggable Transceivers 0, 1, 2, 3, 4, 5, 6, 7, or 8, C = Number of Multimode Pluggable Transceivers 0, 1, 2, 3, 4, 5, 6, 7, or 8 |
Simplex LWL-Kabel
| Manuf. Part No | | Part Description |
| CBL-000-F5-000 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 0,15 m |
| CBL-000-F5-001 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 0,3 m |
| CBL-000-F5-002 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 1,5 m |
| CBL-000-F5-003 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 3,0 m |
| CBL-000-F5-004 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 7,5 m |
| CBL-000-F5-005 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 15 m |
| CBL-000-F5-006 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 24 m |
| CBL-000-F5-008 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 45 m |
| CBL-000-F5-009 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 61 m |
| CBL-000-F5-016 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 304 m |
Duplex LWL-Kabel
| Manuf. Part No | | Part Description |
| CBL-000-F6-000 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 1 m |
| CBL-000-F6-001 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 2 m |
| CBL-000-F6-002 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 3 m |
| CBL-000-F6-003 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 5 m |
| CBL-000-F6-004 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 10 m |
| CBL-000-F6-005 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 20 m |
| CBL-000-F6-006 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 30 m |
| CBL-000-F6-007 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 50 m |
| CBL-000-F6-008 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 70 m |
| CBL-000-F6-011 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 130 m |
| CBL-000-F6-012 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 150 m |
| CBL-000-F6-013 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 170 m |
Kundenspezifische Kabellängen sind möglich, bitte fragen Sie die Länge, die Sie benötigen an.
|
