Manageable Industrial Gigabit Ethernet Switches, 9-Port 1000BASE-T Ethernet, (4 x PoE+)
|
The GL900 is a 9-port PoE+ capable manageable Gigabit Ethernet switch board, designed for rugged industrial applications. The PCB is provided with 1000BASE-T RJ45 jacks at the front, and in addition a SFP cage at the rear edge for switch expansion. Four front ports are enabled for 802.3at Power-over-Ethernet, up to 120W in total.
The GL900 is equipped with the Marvell® 88E6390 (Peridot) Gigabit Ethernet switch, and in addition the Marvell® Armada® 88F3700 SoC (ARM® v8 Cortex-A53). While the switch is basically self-managed, the CPU enables flexible management features and prominently AVB/TSN operation, by means of the optional software stack.
Features
- 1000BASE-T Ethernet switch, 9 + 1 ports
- PCB assembly, intended for rugged industrial applications, ready-for-use (Embedded Gold)
- 9 x RJ45 Gigabit Ethernet front connectors
- 4 x 802.3at PoE+ (up to 30W/port)
- PoE+ support up to 120W in total
- 1 x SFP 2500BASE-X rear connector
- Self-managed operation, or ARM® V8 CPU management support
- Protocol options e.g. AVB/TSN & VLAN
- PCB Dimensions: 152mm (W) x 139mm (D) w/o connector overlap
- Rear edge 4-pos. circular power adapter connector
- Nominal 48VDC/54VDC power input operation
Please refer to the datasheet for more information
Please contact Systerra Computer for ordering options
|
|
