GL700
Add to Info-List

Single Pair Ethernet Switch: 5 x 100BASE-T1, 2 x 1000BASE-T 4-Way Power + Data M8 Hybrid Connectors IEC 63171-6

The GL700 Embedded Gold is a Single Pair Ethernet (SPE) switch designed for rugged industrial applications. The PCB assembly is provided with five 100BASE-T1 (IEEE 802.3bw) ports and in addition two 1000BASE-T RJ45 jacks for uplink and port expansion.

The 4-way circular M8 Hybrid SPE connectors are covered by the IEC 63171-6, combining power and data distribution. Any GL700 SPE port can deliver up to 2.3A at voltages up to 57V, individually protected by an eFuse.

The M12-A power input connector accepts 9-57VDC. As an option the board can be equipped with a terminal block power connector. The GL700 is equipped with the Marvell® 88Q5072 Automotive Ethernet switch and is configured by default for self-managed operation. Its PHYs are fully inter-operable with the Open Alliance BroadR-Reach® (OABR) standard for automotive connectivity.

The GL700 is an assembly of the basic PCB and a riser card which accommodates the M8 Hybrid connectors. Switch port expansion (daisy-chaining) can be easily achieved by means of RJ45 Ethernet patch cables, connecting two or more GL700 together. As GL710, the switch is also available with a mezzanine CPU card (GC370) for additional protocol support such as AVB/TSN, and Wi-Fi 6 wireless communication.

Features
  • 100BASE-T1 IEEE 802.3bw Ethernet switch
  • PCB assembly, intended for rugged applications, ready-for-use (Embedded Gold)
  • 5 x M8 Hybrid circular connectors (data & power), IEC 63171-6 (style 6J-M8CI), 100BASE-T1
  • 2 x RJ45 1000BASE-T Gigabit Ethernet connector
  • Intended for industrial and automotive use
  • Self-managed operation
  • AVB/TSN protocol stack under development
  • PCB Dimensions (basic card): 133mm (W) x 78mm (D) w/o connector overlap
  • M12-A DC power connector
  • Sales option terminal block power connector
  • 9-57VDC power input operation
  • GC370 CPU card can be stacked for AVB/TSN protocol support
Applications
  • Industrial networks - IIoT
  • AVB/TSN ready
  • Automotive gateway
  • In-vehicle networking
  • Automotive test equipment
  • Rugged environments
  • Edge computing
  • Transportation
  • Construction vehicles
  • Harvester
Please refer to the datasheet for more information
Please contact Systerra Computer for ordering options
