The GC600 basic card is equipped with an Intel® E39xx processor, and offers two connectors each for DisplayPort monitors, USB3 and M12-X Gigabit Ethernet at the front edge. The board is provided with 8GB soldered ECC RAM and a PCIe® SSD M.2 socket. The M12 power input connector accepts 9-57VDC.
As GC610 assembly, the GC600 basic PCB in addition accommodates the GC010 mezzanine module, enabling wireless communication. The mezzanine card provides two M.2 sockets, suitable for both a Wi-Fi 6 (ax) and Bluetooth module, and also a WWAN modem 4G/5G & GNSS.
The GC600/GC610 is a high reliable solution for industrial environments as well as transportation and railway.
Highlights
- Low power X86 based single board computer (SBC)
- Intended for rugged industrial applications, ready-for-use (Embedded Go®)
- Industrial PCB assembly
- PCB Dimensions 133.0mm x 138.0mm (h x w)
- Intel® Apollo Lake-I (APL-I) SoC E39xx processor series (scalable GC600/GC610 versions)
- Versatile standard I/O connector suite (dual DisplayPort, dual USB 3.0, dual M12-X GbE)
- Choice of two versions - without (GC600) or with (GC610) wireless networking WLAN - WWAN - BT
- SMA/SMA-RP antenna connectors (GC610)
- M12 power connector
- Option terminal block power connector
- Wide range DC power input operation 9-57V
APPLICATIONS
- Ultra compact industrial PC
- X86 code compatibility for rapid time to market
- Machine control
- Kiosk systems, information panels
- Dual 4k display solution, independent operation
- Single display or headless applications
- Industrial networks - IIoT
- Cable and wireless networking
- Router, bridges
- Rugged environments
- Edge computing
- Vehicles, transportation
Security
- Trusted Platform Module (option)
- TPM 2.0 for highest level of certified platform protection
- Infineon Optiga™ SLB 9665 cryptographic processor
- Conforming to TCG 2.0 specification
- AES hardware acceleration support (Intel® AES-NI)
Environmental, Regulatory
- Designed & manufactured in Germany
- Certified quality management according to ISO 9001
- Long term availability
- Rugged solution
- Conformal coating, sealing, underfilling on request
- RoHS compliant
- Operating temperature -40°C to +85°C (industrial temperature range)
- Storage temperature -40°C to +85°C, max. gradient 5°C/min
- Humidity 5% ... 95% RH non condensing
- Altitude -300m ... +3000m
- Shock 15g 0.33ms, 6g 6ms
- Vibration 1g 5-2000Hz
- Protection class IP20
- EC Regulatory EN55024, EN55032, EN62368-1 (CE)
Consult the attached datasheet for more features and options.
