Highlights
- Single Board Microcomputer for general use and networking management
- Marvell® ARMADA® 3700 SoC family
- Intended for rugged industrial applications, ready-for-use (Embedded Go®)
- Industrial PCB assembly
- PCB Dimensions 133.0mm x 78.0mm
- 88F3710 single-core
- 88F3720 dual-core
- Low power consumption under different workloads
- Optimal performance-per-Watt in the embedded markets
- M12-A Power connector
- Terminal block power connector (option)
- Wide DC power input operation 9-57V
APPLICATIONS
- Industrial networks - IIoT
- Industrial, factory and building automation
- Rugged environments
- Edge computing
- Transportation
- Railway
- AP Routers
- Multi-protocol gateways
- Host management for networking (AVB/TSN)
- GC370 can be combined with unmanaged Embedded Go® switch boards via 2.5GbE I/F
- Customized connector loading
- Customized board design
Environmental, Regulatory
- Designed & manufactured in Germany
- Certified quality management according to ISO 9001
- Long term availability
- Rugged solution
- Conformal coating, sealing, underfilling on request
- RoHS compliant
- Operating temperature -40°C to +85°C (industrial temperature range)
- Storage temperature -40°C to +85°C, max. gradient 5°C/min
- Humidity 5% ... 95% RH non condensing
- Altitude -300m ... +3000m
- Shock 15g 0.33ms, 6g 6ms
- Vibration 1g 5-2000Hz
- Protection class IP20
- EC Regulatory EN55024, EN55032, EN62368-1 (CE)
Consult the attached datasheet for more features and options.
Please contact systerra computer GmbH for options
|
