The GC100 is a Single-Board-Computer intended for AI and real-time edge computing. Equipped with the Nvidia® Jetson Xavier™ NX SoM, the board was designed for rugged industrial applications such as IIoT or image processing.
The GC100 SBC provides typical I/O connectors, e.g. DisplayPort, Ethernet, and USB. A PCIe® M.2 SSD is available as on-board mass storage.
The GC100 comes with the L4T (Linux for Tegra) development suite by Nvidia®, customized by EKF.
For wireless networking, the GC100 can be paired with the matching GC102 mezzanine card, equipped with M.2 connectors for 4G/5G WWAN and dual Wi-Fi 6 modules.
The GC100 SBC can be configured as master or slave in distributed multi-processing applications. For this purpose the board is provided with four Samtec FireFlyT Flyover® connectors, each suitable for a PCI Express® Gen3 x4 based fiber optical cable up to 100m, or Twinax copper cable assembly. Moreover, the PCIe® interfaces can also be used for attachment of demanding peripheral devices such as high resolution cameras.
Highlights
- NVIDIA® Jetson Xavier™ NX based platform
- Single or dual PCB assembly
- Intended for rugged industrial applications, ready-for-use (Embedded Gold)
- Industrial PCB assembly - basic board GC100 and optional expansion board GC102
- PCB Dimensions 138.0mm x 133.0mm
- M.2 NVMe SSD socket
- Option 4 x PCI Express® x4 MPO/MTP optical cabling ports
- Versatile standard front I/O connector suite (DisplayPort, USB GbE)
- Option dual Wi-Fi 6 modules (GC102)
- Option WWAN 4G/5G module (GC102)
- Option SMA/SMA-RP antenna connectors (GC102)
- M12 power connector
- Option terminal block power connector
- 9-57VDC wide range power input operation
APPLICATIONS
- Artificial Intelligence CUDA® based edge computing
- Distributed edge computing, real-time AI
- PCIe® based optical cabling to slave ECUs
- Industrial networks - IIoT
- Ethernet based cable and wireless networking
- 4G/5G networking
- Data acquisition
- Kiosk systems, information panels
- Dual 4k display solution, independent operation
- Single display or headless applications
- Rugged environments
- Vehicles, transportation, harvesting, construction machines
- Robotics
- Surveillance, mapping
- ADAS test equipment
Environmental, Regulatory
- Designed & manufactured in Germany
- Certified quality management according to ISO 9001
- Long term availability
- Rugged solution
- RoHS compliant
- Operating temperature -40°C to +85°C (industrial temperature range)
- Storage temperature -40°C to +85°C, max. gradient 5°C/min
- Humidity 5% ... 95% RH non condensing
- Altitude -300m ... +3000m
- Shock 15g 0.33ms, 6g 6ms
- Vibration 1g 5-2000Hz
- Protection class IP20
- EC Regulatory EN55024, EN55032, EN62368-1 (CE)
Consult the attached datasheet for more features and options.
Please contact Systerra Computer GmbH for options
|
