Foremay’s EC188 Family SSD drives are the next generation in solid state drive
technology, designed with high performance, high capacity and high reliability for
rugged servers. For example, with a maximum read/write speed up to 4.0/3.3
GB/sec and capacity up to 32 TB, the EC188 Family is the fastest SSDs geared
towards applications that require ultra-high speed and IOPS, long life and high
concurrent access.
The EC188 family solid state drives are geared specifically for ruggedized server
applications that require high concurrent access, large capacity, high IOPS and
speed, and high reliability.
EC188 series application examples are
- Rugged Servers (NAS, SAN, RAID)
- HPEC
- Industrial PCs
Ordering Options
| Form Factor | | R/W Speed, Max. (MB/s) | | Read/Write IOPS | | Capacity (GB) | | Optional Features |
| VPX 3U | | 4,000/ 3,300 | | 100K/100K | | 1TB~32TB | | HE, S1 |
| 2.5” NVMe U.2 | | 3,000/2,200 | | 300K/270K | | 1TB~8TB | | HE, S1 |
| PCIe x8 Gen 3.0 | | 3,800/3,100 | | 100K/100K | | 1TB~8TB | | HE, S1 |
| PCIe x8 Gen 2.0 | | 2,400/2,200 | | 380K/380K | | 1TB~8TB | | HE, S1 |
| PCIe x4 Gen 2.0 | | 1,500/1,400 | | 200K/180K | | 1TB~12TB | | HE, S1 |
| PCIe x4 Gen 1.0 | | 800/700 | | 55K/25K | | 4TB~32TB | | HE, S1 |
| PXIe | | 3,500/ 3,300 | | 100K/100K | | 1TB~8TB | | HE, S2 |
| VPX 6U | | 4,000/ 3,300 | | 100K/100K | | 1TB~32TB | | HE, S1 |
| 2.5” SATA III | | 550/510 | | 70K/70K | | 1TB~16TB | | HE, S1 |
| Optional Features |
| RC: Rugged connectors with 100K mating cycles |
| S1 & S2: software / hardware secure erase |
| S3: One-key self-destroy secure erase |
| HE: Hardware based encryptions |
| CC: Conformal coating |
| WP: Write protect (read only) |
| OP: TCG-Opal |
|
