APWR35210HR-80W

PCIe/104 80 Watt Filtered Avionics Power Supply

The APWR35210HR-80W filtered avionics embedded power supply module provides a robust solution for PC/104 systems requiring a rugged MIL-type power supply. The wide input voltage range of 16 - 40 VDC will suit applications ranging from communications to aviation.

This power supply is exceptionally suited for powering PCIe/104 systems drawing on noise-filled, unregulated 28 VDC aircraft power. The APWR35210HR-80W is highly recommended for systems requiring 3.0 Amps of 12 VDC, such as those using RTD's Quad-Core Intel Core i7 CMA34CRQ2100HR SBC.

Features
  • PC/104 Form Factor
  • PCIe/104 Stackable Bus Structure
    • PCIe universal expansion bus (Type 1 or Type 2)
  • Outputs
    • +5 VDC at 10 Amps for 40 Watts
    • + 12 VDC at 1.67 Amps for 40 Watts
    • + 3.3 VDC at 1.0 Amps for 3 Watts
  • Input: 16...40 VDC
  • High Reliability
    • Reverse polarity and transient protection
    • Isolation voltage 500 V
    • 50 V for 100 msec (meets MIL-STD-704F Voltage Transients for 28 Volt DC system)
    • Uses Mil modules that meet MIL-STD-461 D, E, and F CE102, CS101, CS114, CS115
    • Remote ON*/OFF and ON/OFF*
    • Operating Temperature: -40...+85°C
Ordering Options
Manuf. Part No    Part Description
APWR35210HR-80W  PCIe/104 80 Watt Power Supply with PC/104 Stand-Off Kit

Accessories
Manuf. Part No    Part Description
AC/DC PS  AC to DC Power Converter for use with RTD DC/DC Modules

Rugged, stackable IDAN Version available. Please contact systerra.
