APWR18110HR-70W

PCI-104 70 Watt Filtered Avionics Power Supply

The APWR18110HR-70W filtered avionics embedded power supply module provides an elegant solution for PC/104 systems requiring a rugged MIL type power supply for PC/104 applications. The wide input voltage range of 16...40 VDC will suit applications ranging from communications to aviation.

The APWR18110 is exceptionally suited for powering PC/104 systems drawing on noise-filled, unregulated 28 VDC aircraft power.

Features

PCI-104 stackable bus structure
Outputs
• +5 VDC at 10 Amps for 50 Watts
• + 12 VDC at 1.67Amps for 20 Watts
Input: 16...40 VDC
High Reliability
• Reverse polarity and transient protection
• Isolation voltage 500 V
• 50 V for 1 second
• Uses Mil modules that meet MIL-STD-461C CE03 and meets MIL-STD-461D and CE102
• Mil modules protect against voltage spikes specified in MIL_STD-461C and conducted susceptibility specified in MILSTD-461C, CS01 and CS02
• Mil modules reduce reflected noise of the DC-DC converters to meet MILSTD-461C CE03 and MILSTD-461D CE102 limits
• Remote ON*/OFF and ON/OFF*
• Hermetically sealed

Industry Applications

Military and Aerospace Applications
Airborne and Mobile Applications
Industrial and Medical Systems
Communication Systems

Also available in a stackable, rugged IDAN enclosure: IDAN-APWR18110HR-70W

Ordering Options

Manuf. Part No		Part Description
APWR18110HR-70W		PCI-104 70 Watt Power Supply

Accessories

Manuf. Part No		Part Description
AC/DC PS		External AC/DC Power Supply
