AC/DC PS

AC to DC Power Converter for use with RTD DC/DC Modules

AC to DC Power Converter for use with RTD DC/DC Modules

Features

AC to DC Power Converter
2-wire stranded
Input
- Standard three prong power connector
- 110-240 VAC 2.5-1.2A @ 50-60 Hz
Output
- 2-pin quick release terminal block connector (standard on RTD power supplies)
- 24 VDC 2.7A
Includes AC power cable
Other configurations available:
- IDAN configuration for AC/DC PS-190
- AC/DC Power Supply for use with ATX3510-190W
- AC/DC Power Supply for use with IDAN-ATX3510-190W
Physical Attributes
Size (approximate):
- Length: 4.50 inches (114.30 mm)
- Width: 2.06 inches (52.39 mm)
- Height: 1.50 inches (38.10 mm)
- Cable length 54 inches
- AC power cable length 68 inches
Weight (approximate): 1.00 lbs (0.46 Kg)
Operating Temperature: 0...+40°C, 20% to 80% humidity non-condensing
Storage Temperature: -20...+60°C, 10% to 90% humidity non-condensing

Ordering Options

Manuf. Part No.		Product Description
AC/DC PS		External AC Power Supply
IDAN-AC/DC PS		IDAN configuration of AC/DC PS
