ACC 5597 HUB
Add to Info-List

10 Ports Reflective Memory Managed Hub using small Form Factor pluggable (SFP) Transceivers

Networking: Up to ten (10) SFP+ transceivers that can be configured as either one (1) group of ten (10) ports, labeled 1x10, or two (2) groups of five (5) ports, labeled 2x5 controlled by a GANG switch

LAN: One (1) 10/100/1000Base-T ethernet port with access via web-based interface

Features
  • Low latency, deterministic data transfer for high performance and predictability
  • Provides up to ten (10) ports using small form factor pluggable (SFP) transceivers
  • Hubs can be linked to support up to 256 RFM nodes
  • Can support multi-mode simplex / duplex cables up to 300m in length and 10km in length for single mode
  • 100Base-T Ethernet TCP/IP port and RS232 port for remote access and control
  • Internal AC universal power supply
  • Create a single, shared memory network across diverse systems that is OS and bus structure independent
  • Can support networks speeds of up to 10Gb/s
  • 19” rackmount with custom rugged slider options in various depths
  • Automatic bypass of defective or discontinued nodes
  • Can support self-diagnostic capabilities for the health of the network
  • Easy ability to reset the Hub to factory default settings
Applications
  • Aircraft simulators
  • Automated testing systems
  • Ship and submarine simulators
  • Aluminum rolling mill
  • Power plant simulators
  • Industrial process control
  • Engine test stands
  • High-speed data acquisition
  • PLCs
Please refer to the attached datasheet for ordering options or contact Systerra
