The ACC-5595 is a managed hub designed to operate with the Abaco Systems 5565 family of Reflective Memory real-time network products. The Reflective Memory hub can automatically bypass ports when it detects a loss of signal or the loss of valid synchronization patterns, allowing the other nodes in the network to remain operational.
Since the optical ports are implemented with small form factor pluggable (SFP) transceivers, only the required ports need to be populated. The ACC-5595 SFP transceivers can be a combination of either multimode (short distance) or single-mode (long distance) transceivers. This feature permits a cost saving in small networks as well as system optimization.
For larger networks, several ACC-5595 assemblies can be cascaded, permitting a managed hub array with up to 256 nodes. Each port regenerates the serial optical signal, eliminating the problems with insertion losses and cable attenuation. Signal regeneration also reduces jitter. The RS232 port gives you the ability to monitor and control your Reflective Memory network through a simple PC serial port.
The Ethernet port feature allows you to monitor and control the hub from great distances through a local area network (LAN) or via a Web browser.
As an option, the ACC-5595 can be configured as a 19-inch 1U rack-mountable enclosure or as a desktop enclosure. The universal power supply permits operation with nearly any international power standard.
Features
- For use with abaco 5565 Reflective Memory network of products
- Provides up to eight ports using small form factor pluggable (SFP) transceivers
- Hub assemblies can be cascaded with a maximum of 256 nodes
- Automatically bypasses defective or disconnected nodes in a fiber-optic network
- Automatic bypass can be optionally controlled by the loss of signal or by the loss of sync pattern
- Each port regenerates the serial optical signal, eliminating link losses and reducing jitter
- Configurable for use with cables up to 10 km in length
- 10BaseT Ethernet TCP/IP port for remote access and control
- RS232 port for local access and control
- Optional 19-inch 1U rack mount or desktop enclosure
- Internal universal power supply
- Dark on Dark option turns off the board’s transmitter if the receiver does not detect a signal (available for firmware versions 02.00 and later)
Ordering Options
| Manuf. Part No | | Part Description |
| ACC-5595-2BC | | 2 Gb/s Reflective Memory Hub Assembly Rack Mount or Desktop |
B = Number of single-mode (10 km) pluggable Transceivers (0 to 8)
C = Number of multi-mode (300 m) pluggable Tranceivers (0 to 8)
Sum of B + C must less or equal to 8. For distances > 10 km please call.
Simplex LWL-Kabel
| Manuf. Part No | | Part Description |
| CBL-000-F5-000 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 0,15 m |
| CBL-000-F5-001 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 0,3 m |
| CBL-000-F5-002 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 1,5 m |
| CBL-000-F5-003 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 3,0 m |
| CBL-000-F5-004 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 7,5 m |
| CBL-000-F5-005 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 15 m |
| CBL-000-F5-006 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 24 m |
| CBL-000-F5-008 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 45 m |
| CBL-000-F5-009 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 61 m |
| CBL-000-F5-016 | | Simplex LWL Kabel; Multimode 62.5/125 μm; Länge 304 m |
Duplex LWL-Kabel
| Manuf. Part No | | Part Description |
| CBL-000-F6-000 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 1 m |
| CBL-000-F6-001 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 2 m |
| CBL-000-F6-002 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 3 m |
| CBL-000-F6-003 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 5 m |
| CBL-000-F6-004 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 10 m |
| CBL-000-F6-005 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 20 m |
| CBL-000-F6-006 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 30 m |
| CBL-000-F6-007 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 50 m |
| CBL-000-F6-008 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 70 m |
| CBL-000-F6-011 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 130 m |
| CBL-000-F6-012 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 150 m |
| CBL-000-F6-013 | | Duplex LWL Kabel; Multimode 62.5/125 μm; Länge 170 m |
Kundenspezifische Kabellängen sind möglich, bitte fragen Sie die Länge, die Sie benötigen an.
|
