7L600
Add to Info-List

Single Pair Ethernet Switch 7 x 100BASE-T1, 2 x 1000BASE-T

The 7L600 ModBlox7™ module is a Single Pair Ethernet (SPE) switch designed for rugged industrial applications. The assembly is provided with seven 100BASE-T1 (IEEE 802.3bw) ports and in addition two 1000BASE-T RJ45 jacks. The SPE connectors conform to the IEC 63171-6 industrial style IP20 mating face.

The 7L600 was designed according to the new PICMG® ModBlox7™ standard for open modular computing. This innovative concept does not require a backplane, and allows either DIN rail or wall mounting, and 19-inch sub-rack box mounting as well.

The 7L600 is equipped with the Marvell® 88Q5072 Automotive Ethernet switch and is configured by default for self-managed operation. Its PHYs are fully inter-operable with the Open Alliance BroadR-Reach® (OABR) standard for automotive connectivity. Via the RJ45 jacks, 7L600 modules can be easily cascaded and connected to the enterprise network.

As an option, the switch module is available with an ARM based mezzanine controller card, suitable e.g. for additional protocol support and switch management, and even custom specific additions.

Features
  • PICMG® ModBlox7® I/O module 14HP (71mm width)
  • Typical use in ModBlox7® systems for DIN rail or wall mount
  • Option stand-alone box
  • 100BASE-T1 IEEE 802.3bw Single Pair Ethernet switch module
  • 7 x T1 latching receptacles IP20 according to IEC 63171-6 (2-way data)
  • 2 x RJ45 1000BASE-T Gigabit Ethernet receptacles
  • Intended for industrial and automotive use
  • Self-managed operation
  • Option ARM controller support
  • Metal case, DIN rail bracket or wall mount plate
  • Dimensions: 30mm (W) x 140mm (H) x 70mm (D) w/o DIN rail bracket
  • 12VDC ModBlox7® system power
Applications
  • Industrial networks - IIoT
  • Automotive gateway
  • In-vehicle networking
  • Automotive test equipment
  • Rugged environments
  • Rugged environments
  • Edge Computing
  • Transport
  • Construction vehicles
  • Harvester
Please refer to the datasheet for more details
Please contact Systerra Computer GmbH for ordering options
